Description
UNI-T Series UT15 test pen has the functions: AC/DC voltage measurement (include three-phase AC), phase position indication of three-phase AC, continuity test and single probe measurement (judge null wire or live wire). It can also solve the complex problems of electric, factory automation, etc.
Models in UT15 Series: UT15B, UT15C
Features of UNI-T Series UT15 Waterproof Type Voltage Tester
● AC/DC voltage measurement
● Continuity test
● Single probe measurement
● Phase position indication of three-phase AC
UNI-T Series UT15 Waterproof Type Voltage Tester Technical Specifications
LED AC/DC Voltage Indication
- 12V
- UT15B: 0 ~ 12V
- UT15C: 0 ~ 12V
- 24V
- UT15B: 17V ± 2V
- UT15C: 17V ± 2V
- 50V
- UT15B: 35V ± 5V
- UT15C: 35V ± 5V
- 120V
- UT15B: 80V ± 15V
- UT15C: 80V ± 15V
- 230V
- UT15B: 165V ± 20V
- UT15C: 165V ± 20V
- 400V
- UT15B: 300V ± 30V
- UT15C: 300V ± 30V
- 690V
- UT15B: 510V ± 40V
- UT15C: 510V ± 40V
Phase Rotation Test
- Operating Voltage: 0V ~ 690V
- Frequency Range: 50Hz ~ 60Hz
- UT15B: Yes
- UT15C: Yes
Single Lead (L2) Voltage Detection
- Operating Voltage: 0V ~ 690V
- Frequency Range: 50Hz ~ 400Hz
- UT15B: Yes
- UT15C: Yes
Continuity Test
- Resistance Range: 0 ~ 100kΩ
- Beeper and LED Light Indicator
- UT15B: Yes
- UT15C: Yes
Polarity Detection
- Positive & Negative Detection
- UT15B: Yes
- UT15C: Yes
Features
- Waterproof Rating: IP65
- Auto Range: Yes
- Work Light: Yes
- Low Battery Indication:
- LED and Beeper Turn Off When Battery is Low
- (Short Circuit Two Leads for Check)
LCD AC/DC Voltage Display (UT15C Only)
- Range: 24V ~ 690V
- Accuracy: ±(3% + 5)
General Characteristics
- Power Supply: 2 × 1.5V R03 Batteries
- Display Size (UT15C): 23 × 12 mm
- Product Color: Red and Grey
- Product Net Weight: 210 g
- Product Dimensions (W × H × D): 275 × 51 × 30 mm
Accessories Included
- Batteries
Packaging Information
- Individual Packing: Blister, English Manual
- Standard Quantity per Carton: 30 pcs
- Carton Dimensions: 440 × 395 × 455 mm (0.079 CBM)
- Carton Gross Weight: 17 kg
BRAND: UNI-T
DELIVERY: 7-15 days
WARRANTY: 12 Months
COUNTRY OF ORIGIN: China
Import Duties : Applicable
