Description
UT161 series are reliable true RMS digital multimeters with display counts 6000 (UT161B/D) and 22,000 (UT161E). It can measure up to 1000V AC/DC.
Equipped with audible and visible alarm, this series can provide warning expecially when measuring high voltage/current and temperature.
UT161 series are CE certified, suitable for the European market.
Models in UT161 series: UT161B, UT161D, UT161E
Features of UNI-T Series 1000V True RMS UT161 Digital Multimeters
Certifications: CE, UKCA, cETLus
● True RMS
● Data hold/backlight
● Max/Min/Relative mode
● USB communication● Input protection
● Diode/continuity test
● NCV (audible/visual alarm)
Technical Specifications
AC Voltage (V)
UT161B
- Range: 1000V
- Accuracy: ±(1% + 3)
UT161D
- Range: 1000V
- Accuracy: ±(1% + 3)
UT161E
- Range: 1000V
- Accuracy: ±(0.8% + 10)
DC Voltage (V)
UT161B
- Range: 1000V
- Accuracy: ±(0.5% + 3)
UT161D
- Range: 1000V
- Accuracy: ±(0.5% + 3)
UT161E
- Range: 1000V
- Accuracy: ±(0.05% + 5)
AC Current (A)
UT161B
- Range: 10A
- Accuracy: ±(1.2% + 5)
UT161D
- Range: 20A
- Accuracy: ±(1.2% + 5)
UT161E
- Range: 20A
- Accuracy: ±(0.8% + 10)
DC Current (A)
UT161B
- Range: 10A
- Accuracy: ±(1% + 2)
UT161D
- Range: 20A
- Accuracy: ±(1% + 2)
UT161E
- Range: 20A
- Accuracy: ±(0.5% + 10)
Resistance (Ω)
UT161B
- Range: 60MΩ
- Accuracy: ±(1% + 2)
UT161D
- Range: 60MΩ
- Accuracy: ±(1% + 2)
UT161E
- Range: 220MΩ
- Accuracy: ±(0.5% + 10)
Capacitance (F)
UT161B
- Range: 60mF
- Accuracy: ±(3% + 5)
UT161D
- Range: 60mF
- Accuracy: ±(3% + 5)
UT161E
- Range: 220mF
- Accuracy: ±(3% + 5)
Frequency (Hz)
UT161B
- Range: 10MHz
- Accuracy: ±(0.1% + 4)
UT161D
- Range: 10MHz
- Accuracy: ±(0.1% + 4)
UT161E
- Range: 220MHz
- Accuracy: ±(0.01% + 5)
Duty Cycle (%)
- Range: 0.1% ~ 99.9%
- Accuracy: ±(2% + 5)
Temperature
UT161D
- -40°C ~ 1000°C
- Accuracy: ±(1% + 3)
- -40°F ~ 1832°F
- Accuracy: ±(1% + 6)
Features
- Display Count:
- UT161B: 6000
- UT161D: 6000
- UT161E: 22000
- Bandwidth:
- UT161B: 40Hz ~ 500Hz
- UT161D: 40Hz ~ 1kHz
- UT161E: 40Hz ~ 10kHz
- LPF ACV:
- UT161E: Yes
- LoZ ACV:
- UT161D: Yes
- ACV + DCV:
- UT161E: Yes
- Transistor hFE:
- UT161E: Yes
- Peak Hold:
- UT161D: Yes
- UT161E: Yes
- Analog Bar:
- UT161B: 31 Segment
- UT161D: 31 Segment
- UT161E: 46 Segment
General Characteristics
- Power Supply: 4 × 1.5V Batteries (R03)
- Product Net Weight: 350g
- Product Dimensions: 190 × 90 × 50 mm
Standard Accessories
- Batteries
- Gold-Plated Test Leads
- USB Cable
- Temperature Probe (UT161D)
- Multi-Purpose Socket (UT161E)
- English Manual
Standard Individual Packing
- Gift Box
- Cloth Bag
Packaging Information
- Standard Quantity per Carton: 20 pcs
- Standard Carton Dimensions: 480 × 370 × 325 mm
- Standard Carton Gross Weight: 17.8 kg
Optional Accessories
- Bluetooth / APP Support
• NCV measurement
• Frequency measurement
BRAND: UNI-T
DELIVERY: 7-15 days
WARRANTY: 12 Months
COUNTRY OF ORIGIN: China
Import Duties : Applicable
