UNI-T Pocket-sized UT123/UT123T Residential Multimeter
Estimated delivery between Jun 30 to Jul 15
- Description
- Features
- Specifications
- Applications
- Additional Information
- Store Policies
- Inquiries
Description
The UT123 is a pocket-sized residential multimeter designed for home use. The compact structure makes it easy to hold in one hand, and the EBTN screen allows users to obtain clear readings at maximum angle, it is also great for working in dark environments.
Models: UT123, UT123T
Features of UNI-T Pocket-sized UT123/UT123T Residential Multimeter
Certificates (UT123T only): CE, UKCA
● Auto range
● Continuity
● Data hold
● LED/buzzer indication: NCV/continuity/battery power
● NCV
● Low battery indication
● Auto power off
● Over voltage alarm: >600V
Technical Specifications
DC Voltage
- Range: 4V / 40V / 400V / 600V
- Accuracy: ±(0.5% + 2)
AC Voltage
- Range: 4V / 40V / 400V / 600V
- Accuracy: ±(1.0% + 3)
Resistance
- Range: 400Ω / 4kΩ / 40kΩ / 400kΩ / 4MΩ / 20MΩ
- Accuracy: ±(0.8% + 2)
Temperature
- Range: -40°C ~ 300°C / -40°F ~ 572°F
- Accuracy: ±4°C
Features
- Display Count: 4000
- Auto Range: Yes
- NCV Detection: Yes
- Continuity Test: Yes
- Acousto-Optic Indication (NCV / Continuity / Battery Power): Yes
- Low Battery Indication: ≤ 2.7V
- Data Hold: Yes
- Auto Power Off: 15 Minutes
- Operating Temperature: 0°C ~ 40°C
- Safety Rating: CAT III 600V
General Characteristics
- Power Supply: 2 × 1.5V Batteries (R03)
- Display Size: 44 × 26 mm
- Product Color: Red and Grey
- Product Net Weight: 130g
- Product Dimensions: 130 × 65 × 28 mm
Standard Accessories
- Batteries
- Thermocouple
Standard Individual Packing
- Gift Box
- User Manual
Packaging Information
- Standard Quantity per Carton: 60 pcs
- Standard Carton Dimensions: 480 × 340 × 325 mm
- Standard Carton Gross Weight: 15.5 kg
• Resistance measurement
• Temperature measurement
• Voltage measurement
• NCV measurement
BRAND: UNI-T
DELIVERY: 7-15 days
WARRANTY: 12 Months
COUNTRY OF ORIGIN: China
Import Duties : Applicable
